VSP-300

The BioLogic VSP-300 is a modular multi-channel electrochemical workstation that brings the high-performance measurement capability of the SP-300 potentiostat into a multi-channel platform. Where the VSP-3e provides up to 4 channels with standard research-grade performance, the VSP-300 scales this up to more channels while maintaining the SP-300’s superior measurement specifications — the highest current resolution, best EIS phase accuracy, and widest compliance voltage — on each independent channel.

The VSP-300 chassis accepts multiple SP-300 module cards, with each slot providing a complete, fully independent SP-3400class potentiostat/galvanostat channel. The number of channels depends on the chassis configuration, enabling systems with multiple slots for demanding high-throughput measurement programs that cannot tolerate the compromises of lower-specification multi-channel instruments. Each channel can run a completely different electrochemical technique, at independent settings, on a separate cell, all simultaneously — the full multi-channel independence of the VSP platform combined with the premium measurement quality of the SP-300.

This combination makes the VSP-300 the instrument of choice for research programs where both multi-channel throughput and high measurement quality are required simultaneously: comparative EIS studies of many coatings or electrode materials where EIS accuracy is critical; parallel corrosion measurements requiring low-current resolution; multi-sample battery studies where coulombic efficiency tracking demands high measurement precision; or any other scenario where the constraints of lower-spec multi-channel instruments would compromise data quality. NewRoad provides the BioLogic VSP-300 in Israel for research and industrial laboratories requiring high-performance simultaneous multi-channel electrochemical measurements.
