SP-150e

The SP-150e is designed to grow alongside a lab’s research needs. Users can select a configuration at purchase, including a second channel and an EIS option, and later upgrade the instrument themselves, in their own lab, without sending it back to the factory. This modularity means researchers are not locked into their initial setup and will not need to replace the instrument as projects evolve.

A native current range of 10 µA to 1 A comes standard, extendable down to 1 nA with a low current module, or up all the way to 800 A when paired with up to four external FlexP0012 boosters. This range makes the SP-150e particularly suited to high current, energy focused applications such as batteries, supercapacitors, redox flow batteries, and fuel cell or electrolyzer testing, including RRDE compatibility.

Three EIS quality indicators (THD, NSD, NSR) allow users to validate impedance measurements with confidence, while Z Fit EIS fitting software is embedded directly in EC-Lab, so data can be analyzed without exporting to another program. Ethernet connectivity allows multiple potentiostats to be controlled from a single computer, or one instrument to be shared across a team, supporting collaborative lab environments.
